Inlet connector type: horn port,
Inlet size [inch]: 1/2 in,
Outlet port type: horn port,
outlet size [inch]: 1/2 in,
Moisture indicator: I indicator,
Inlet Internal/external: External
Item NO.:
SGI 12Order(MOQ):
1-3Payment:
30% T/T as the deposit and 70% of the balanceMarket Price:
$17.6Price:
$14.65Product Origin:
made in ChinaColor:
as pictureShipping Port:
GuangzhouLead Time：
45Gross weight 0.22 kg
Net weight 0.21 kg
EAN 5702422027805
REACH Candidate List substances >0.1% Cobalt dichloride (CAS no. 7646-79-9), lead (CAS no. 7439-92-1)
Product Name: Sight glass
Product series: Sight glass
Product accessories: General accessories
Outlet Internal/External: External
Export size [mm]: 12 mm
Outlet size [inch]: 1/2 in
Egress interface type: Horn port
Refrigerant(s) R22
Quantity per pack: 25 pc
Temperature range [°C] [min.]: -50 °C
Temperature range [°C] [max.]: 80 °C
Temperature range [°F] [max.]: 175 °F
Temperature range [°F] [min.]: -58 °F
Green: Maximum moisture status @ 25 °C R22: 150 ppm
Green: Maximum moisture status @ 43 °C R22: 250 ppm
Inlet Internal/External External
Inlet size [mm] :12 mm
Inlet size [inch]: 1/2 in
Inlet interface type: horn mouth
Connection material: brass
Body material: brass
Yellow: Minimum moisture condition @25 °C R22: 300 ppm
Yellow: Minimum moisture condition @43 °C R22: 500 ppm
Packaging method: multi-packing
Serviceable: number
Water content indicator: I indicator
Model: SGI 12
Maximum working pressure [bar]: 35 bar
Maximum working pressure [psig]: 500 psig
Previous:
Refrigeration anti copper vibration tubeNext:
Danfoss DML Fully enclosed filter drier, low temperature cast steelIf you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
